Ainsworth(AGT) A-STAR A727 A-STAR Curve A743

A-STAR Curve XL A755 Button Panel Deck




agt-curve-slot

The Touch monitor support the 1280(H)*248(V) screen format and 16.7M colors.

It use the P-CAP touch technology. The interfaces are 43020-6P female，DP，DVI Input Video Source and USB-B type.


Deck Model

Deck Part No.

Monitor Model

QM-151BD-OPCR10

025119

TOT151FEPC-V2

Product  Images
ainsworth-a-star-a727-a-star-curve-a743-a-star-curve-xl-a755-button-panel-deck-tot151fepc-v2-02
ainsworth-a-star-a727-a-star-curve-a743-a-star-curve-xl-a755-button-panel-deck-tot151fepc-v2-04
ainsworth-a-star-a727-a-star-curve-a743-a-star-curve-xl-a755-button-panel-deck-tot151fepc-v2-03
ainsworth-a-star-a727-a-star-curve-a743-a-star-curve-xl-a755-button-panel-deck-tot151fepc-v2-06
ainsworth-a-star-a727-a-star-curve-a743-a-star-curve-xl-a755-button-panel-deck-tot151fepc-v2-05

"How are your displays different from

the generic ones?"

This is one of the questions we hear most often from customers.
Our answer is simple: Technology drives value. Capability guarantees results.
stability
The best experience

Extreme testing for

guaranteed reliability


We choose the best LCD
panels, and build everything
else ourselves
From the design stage, every TMD display uses
only A-grade materials, and once complete,
must pass a series of rigorous tests, including:
Our LCD panels are sourced from world-renowned
brands such as LG and AUO, always A+ grade,
ensuring the highest level of image quality,
brightness, and lifespan.
-  ESD (electrostatic discharge) tests
-  High & low temperature cycling
-  Salt and alkali resistance tests
-  Vibration tests
-  Drop tests
Aside from the LCD panel, nearly every other
component inside our displays — driver boards,
controller cards, interface boards, lighting modules,
and more — has been progressively replaced with
TMD-designed and manufactured modules.

Every model we release is proven under extreme

conditions. If it doesn’t pass, it doesn’t

leave the factory.

All our modules are engineered to industrial-grade
standards, with many using automotive-grade or
even military-grade materials, ensuring they can
withstand long operating hours and harsh
conditions while maintaining stable performance.
stability
Customized R&D

Generic assembly vs.

custom engineering


Fully self-developed

modulesfor stronger system

compatibility


Many low-cost displays in the market are simply
“generic panel + generic driver board + housing”.
They may look cheap, but :
Our internal modules include:
-  LCD driver boards
-  RGB lighting controllers
-  Bash Button controllers
-  USB/serial interface boards
-  LED strip controllers
-  Poor module compatibility
-  Messy control logic
-  Inconsistent hardware between batches
-  Failure often means replacing the entire unit

In the slot machine industry, where machines run
24/7 for years, stability, maintenance efficiency,
and unified standards are critical.

All are designed, tuned, and updated by the TMD
engineering team, ensuring strong system
compatibility, easy firmware updates, convenient
maintenance, and no risk of discontinued parts.

Brand, service
Technical Services

R&D is the core of product

value


Premium materials + strict

manufacturing


Our pricing reflects:

We only use brand-new A-grade materials
— never refurbished or recycled.
From SMT assembly and electrical testing to
burn-in, every step follows strict process standards.
Yes, it costs more, but quality is worth it.

-  Investment in system architecture
-  Long-term technical support capability
-  Rapid and flexible customization
-  Ongoing upgrade and maintenance assurance


If all you need is a screen that “turns on”, the
market has cheaper options. But if you want a
reliable, upgradable, and long-term
maintainable system, our products are the
right choice.

In summary

You’re not just buying a display. You’re getting:
-  A complete integrated system
-  A platform built for upgrades and maintenance
-  A technical team that’s always ready to respond
-  A manufacturer that takes responsibility seriously


TMD Technology — Innovation Gaming Device Lab.
Mechanical ​
Product Model
Product Dimension
Net Weight
Gross Weight
TOT151FEPC-V2
535.2mm x 151mm x 56.8mm
2.49kg

3.15kg

LCD Display
15.1 inch
377mmx74mm
1280*248
TBD
16.7M
26：5
TBD
250cd/cm²
LED Lighting Bar Type
89/89/89/89
Panel Size
Active Area
Number Of Pixels
Pixels Pitch
Display Colors
Scale Ratio
C/R
Brightness
Back-Light
Viewing Angle Range
Touch Screen
Touch Technology
Touch Points
Touch Construction
Touch Cover
Interface
Luminousness
Input Source
Touch Accuracy
Response Speed
Supports OS
Technical Service
Firmware Upgrade
​
P-CAP
10Points（Max）
G+G
Glass T=2mm
USB-B Female
≥85%
Finger
2mm（Central）， 2. 5mm（Edge）
<10ms
Windows xp/7/8/10, Linux, Android, MacOS
Customize protocol for USB and RS232 interface
Supports Upgrade Firmware Via USB Interface
Environmental
Operating：0°C~45°C

Storage：-20°C-55°C



Operating：10%-80%RH, 40°C
Storage：10%-80%RH, 40°C

Temperature




Humidity

Dimensions

tot151fepc-v2 Dimensions

Quality Assurance

  • 2011

  • 07-07

Products are assembled in a dust-free workshop,
all accessories are made of raw materials, no second hand materials.

tmdtouch-workshop-1
tmdtouch-workshop-2

FAQ

Q1.What services do we provide?
TMDtouch is a technology-driven R&D and manufacturing company, specializing in the touch and display field for 13 years, and has been designing and manufacturing touch display hardware for the gaming industry for over 10 years.
We design and manufacture P-CAP, Touch Monitor, Monitor, Button Panel, etc.
Additionally, we independently design and manufacture hardware components like touch controllers, power controllers, LCD drivers, and light controllers used in touchscreens and display devices.
Therefore, we offer various products and customized solutions in the touch and display field, especially for gaming industry hardware, and provide direct technical support.
Q2. How to purchase products and services? What is our response time?
You can organize your requirements and send them via email to Sales@tmdtouch.com. Our sales team will respond within 12 hours.
Q3. What is the delivery time?
Samples: 15-45 days after receiving the sample fee (customized products);
Goods: 15-30 days after receiving the payment.
Q4. What payment methods are available?
T/T, Paypal; full payment is required after placing the order.
Q5. How do you control product quality?
We own our factory, and each product undergoes at least 10 strict quality inspections before shipping.
Q6. What is the warranty period for the products?
The standard product warranty is 1 year, depending on the product. We offer lifetime paid technical support after the warranty period.
Q7. What is your after-sales service?
We provide 7x24 online technical support. If needed, we can dispatch technicians within 3-7 days in Asia, North America, Australia, and Europe.
Q8. What packaging methods and shipping options do you use?
Packaging includes anti-static bags, air cushion bags, pearl cotton pads, and sturdy gravity cartons.
For sea shipping, we provide export wooden crates.
Samples and small quantities are shipped via DHL, FedEx, UPS, with shipping costs borne by the buyer.
Larger quantities are shipped by air or sea, with shipping costs borne by the buyer.
